- The Ideal Choice: Smaller, lighter and redder, the Revo Voron is the HotEnd of choice for Voron 3D printers, which uses the smallest radiator we have produced to date, weighing just 25 grams, and has a more flexible motion system. Revo Voron is designed for direct drive Settings and is fully compatible with the Revo ecosystem you can enjoy all the benefits of E3D's RapidChange Revo system
- RapidChange Nozzles: Revo Voron is compatible with Revo nozzles, which allow for quick, finger-tip changes at room temperature. Revo nozzles form a closed system of nozzle and heatbreak, which prevents unwanted material discharge. Assembly is incredibly easy
- Improved Performance: The Revo Voron uses a Revo HeaterCore, an innovative hotend heater and sensor architecture. It reaches temperature much faster than a traditional aluminium heating block. Thanks to the positive temperature coefficient (PTC), the Revo HeaterCore works more safely than comparable solutions on the market
- Red Anodised Heatsink：With its red anodised heat sink to complement your Voron accented parts., the hotend fits perfectly with Voron 3D printers. Heatsink is GPL V3 certified
- Compatible with: Voron 1/Voron Trident/ Voron Switchwire/ Voron 2.4/ Voron Legacy/ Voron 0.1. This is a rigid mounted design that uses four M3 x 0.5 bolts to secure to your Voron 3D printer
E3D developed this Revo-compatible cold side in collaboration with Team Voron. It’s intended for use with the Voron StealthBurner, which includes an integrated cold side fan. It’s compatible with our Revo ecosystem, so you can change nozzle size without tools or hot tightening using just your fingers.
Why choose it
- All-metal hotend
- Ideal HotEnd for Voron StealthBurner
- Works with a Revo HeaterCore for faster heat-ups
- Ultra-lightweight construction for improved speed performance
- Uses Revo Nozzles – change nozzles cold, no tools, no hot tightening
- Ready for Revo. A groove at the bottom of the sink accepts a Revo HeaterCore spring. It’s compatible with our Revo ecosystem, so you can change nozzles without tools or hot tightening using just your fingers.
Features
- Max temp: 300°C
- Voltage: 12V or 24V
- Wattage: 40W
- Mounting System: 4 x M3 x 0.5
- Filament diameter: 1.75
- Nozzle type: RapidChange Revo
kit Include
1 x Revo Voron Sink
1 x Revo HeaterCore 12V or 24V
1 x Revo spring
1 x 100mm 1.75mm PTFE
1 x Heater extension cable
1 x Temperature sensor extension cable
Single nozzle kit:
1 x 0.40mm brass Revo Nozzle
Fully loaded nozzle kit:
1 x 0.25, 0.40, 0.60, and 0.80mm brass Revo Nozzles
- Package Dimensions : 8.58 x 5.83 x 1.54 inches; 4.66 ounces
- Date First Available : June 1, 2023
- Manufacturer : BIQU
